Crompton Three Phase Direct On Line Auto Starters

₹100.00

Efficient three-phase auto starters for monobloc and submersible pumps with wide voltage protection and overload safeguards.
Add to wishlistAdd to compare
ENQUIRY!
Categories: , Brand:

Description

The Crompton Three Phase Direct On Line Auto Starters are robust and reliable devices designed to efficiently start and protect three-phase monobloc and submersible pumps. They ensure smooth operation under varying voltage conditions while safeguarding your pump with overload and voltage protection features.

Additional information

brand

Impala

Features

  • Wide Voltage Application: Operates reliably within 250V–450V.
  • Overload Protection: Prevents damage to pumps by tripping overload relays.
  • Pump Protection: Guards against overvoltage, undervoltage, and single-phase issues.
  • Mode of Operations: Automatic start after power restoration, manual operation, and bypass mode.
  • Robust Design: Durable construction for long-lasting use.

Applications

  • Suitable for 3-phase monobloc pumps up to 10 HP.
  • Suitable for 3-phase borewell & openwell submersible pumps up to 7.5 HP.

Technical Specification

Sr. No Model Name Relay Range (A) Voltage Range (V) Suitable for kW/HP – Monobloc Pumps Suitable for kW/HP – Submersible Pumps
1 DOL4065A-2S3M 4.0–6.5 250–450 2.2 / 3.0 1.5 / 2.0
2 DOL60100A-3S5M 6.0–10.0 250–450 3.7 / 5.0 2.2 / 3.0
3 DOL90140A-5S7.5M 9.0–14.0 250–450 5.5 / 7.5 3.7 / 5.0
4 DOL130220A-7.5S10M 13.0–22.0 250–450 7.5 / 10.0 5.5 / 7.5
