Crompton Three Phase Star Delta Control Panels

₹100.00

High-quality star delta control panels for three-phase pumps with wide voltage tolerance, overload protection, and easy-to-use controls.
Add to wishlistAdd to compare
ENQUIRY!
Categories: , Brand:

Description

The Crompton Three Phase Star Delta Control Panels are designed for efficient and reliable operation of three-phase monobloc and submersible pumps. They provide protection against electrical anomalies and ensure consistent pump performance.

Additional information

brand

Impala

Features

  • Wide voltage application (250V–450V)
  • Overload protection to prevent motor damage
  • Heavy-duty contactor for handling high current
  • Pump protections: Overvoltage, Undervoltage, Single Phase Prevention (SPP)
  • Voltmeter & ammeter for monitoring
  • Auto pump ON after restoration of power with manual bypass option

Applications

  • Suitable for 3-Phase Monobloc pumps from 10 HP to 35 HP
  • Suitable for 3-Phase Borewell & Openwell submersible pumps from 6 HP to 30 HP

Technical Specification

Sr. No. Model Name Relay Range (A) Voltage Range (V) Suitable for kW/HP Monobloc Pumps Suitable for kW/HP Submersible Pumps
1 CP90140SD 9–14 250–450 7.5 / 10 4.6 & 5.5 / 7.5
2 CP110180SD 11–18 250–450 9.3 / 12.5 & 11.0 / 15 7.5 / 10.0 & 9.3 / 12.5
3 CP130210SD 13–21 250–450 13.0 / 17.5 11.0 / 15.0
4 CP200320SD 20–32 250–450 15 / 20 & 18.5 / 25 13.0 / 17.5 & 15.0 / 20.0
5 CP280420SD 28–42 250–450 22.5 / 30 & 25 / 35 17.5 / 25.0 & 22.5 / 30.0
