Additional information

brand

Impala

Application

  • Airport & Ship Yards
  • Railway workshops & cleaning yards
  • State transport & workshops
  • Industrial & agricultural purposes
  • Auto two & four-wheel workshops for washing/cleaning applications
  • RO water and seawater high-pressure applications

Operating Range

  • Flow Range: Up to 30,000 LPH
  • Pressure Range: Up to 1000 Kg/cm²
  • Temperature Range: 30°C to 300°C
  • Material of Construction (M.O.C): AISI 316, AISI 304, AISI 410, CS, Alloy-20, Hastelloy C & B, Titanium, Monel, etc.
  • Wet and Cartridge: Single/Double acting (simplex/duplex/triplex/pentaplex) plunger
  • Valve: Ball, Cone, Plate, Wing with or without spring-loaded
  • Gland Packing: U seal (PTFE, Chevron, PU) / Square rope
  • Options: Pressure relief valve, pulsation damper, instrumentation and automation, complete pumping systems
