Additional information
| brand | Impala |
|---|
₹100.00
| Motor HP | 0.25 HP TO 30 HP |
| Head | 4 m – 80 m |
| Capacity | 04 LPM TO 2000 LPM |
| brand | Impala |
|---|
• Milk, Cream, Buttermilk, Condensed Milk
• Fruit Juice, Beer, Wine, Sugar Syrup
• Vitamin Solutions & Sugar Confectionery
• RO Water, DM Water, Pure Water. Water for Injection (WFI)
• Vegetable Oil, Mineral Oil, Lubricating Oil etc.
• Pharmaceutical Formulations, Syrup etc.
• Alkaline Solution / Alcoholic Drinks.
• Acids, Fine Chemicals
• Bottling Plants, Soft Drinks & Distillery
• Food Processing & Liquid Food Applications
• Dyes, Pigments & Paint Industries
• Descaling Applications, Paper & Cement Industries
• Water Treatment Plants
• Detergent, Soaps, Paste & Shampoo
• Textile Sizing, Dyeing & Finishing Systems
• Natural & Synthetic Fibre Processing
• Hot & Cold Water Circulation Systems
• Manufactured from premium rolled stainless steel for superior mechanical strength and corrosion resistance.
• A smooth, non-porous, non-pitting surface minimizes friction losses and product contamination.
• Super-finished surfaces prevent contamination and are ideal for hygienic applications.
• Designed for CIP (Clean-in-Place) and manual cleaning applications.
• Energy-efficient operation with low NPSH requirements for reduced cavitation.
• Handles liquids with viscosities up to 1500 cP.
• The pumps can work under a vacuum of 720 mm of Hg, suitable for vacuum evaporators.
• Pumps are available with open/semi-open impellers.
• The best elastomers are used in the pumps to provide optimum resistance for high temperatures and chemicals.
• Minimum working / rotating parts
• Safe and quiet operation levels.
• Gentle product handling with lower maintenance and downtime cost.
• Dynamic combinations of seal faces as per the customer’s requirement (single seal / double seal, seal external cooling)
• Suitable for standard motor or flange type or foot cum flange type motor or engine
• Monoblock or bare pumps or with trolley
• Flame-proof motor options available on request.
• Multiple connection options, including Tri-Clamp, SMS, BSP Threaded and Flanged Ends.
• Pumps with adjustable legs, available on request.
• Casing: AISI 316 / 316L / 304L / 304
• Impeller: AISI 316 / 316L / 304L / 304
• Wear Plate: AISI 316 / 316L / 304L / 304
• Shaft: AISI 316 / 316L / 304L / 304
• Seal: TC/TC, SIC/SIC, SS/Carbon or even seal in special application
• Motor Cover: SS-304 / SS-202 / SS-316
• Gasket: Viton / Nitrile / Silicon / PTFE
