IMHPP Series Horizontal Polypropylene
IMHPP Series Horizontal Polypropylene - Image 2
IMHPP Series Horizontal Polypropylene - Image 3

IMHPP Series Horizontal Polypropylene

₹100.00

Buy now
IMPALA “IMHPP” Series pumps are heavy-duty, high-performance horizontal polypropylene pumps designed to handle highly corrosive and abrasive chemicals. Built for durability and chemical resistance, the IMHPP Series is ideal for applications in chemical processing, effluent treatment, acid transfer, and other demanding industrial environments. These pumps offer reliable operation, low maintenance, and excellent resistance to aggressive fluids, making them a preferred choice for corrosive liquid handling.

Range

Head Up To 60 mtrs
Pump size 25 mm to 150 mm
Capacity Up to 180 m³/h
Speed 1440 / 2880 RPM @ 50 Hz & 1750 / 3500 RPM @ 60 Hz
Temperature Up to 110°C
Add to wishlist
ENQUIRY!
Categories: , Brand:

Additional information

brand

Impala

Application

  • Water Treatment Plants
  • Effluent Treatment Plants (ETP)
  • Filter Press Systems
  • Fertilizer & Chemical Plants
  • Pharmaceutical Industries
  • Tube Descaling Systems
  • Corrosive Gas Scrubbing Systems
  • Vacuum Ejector Systems
  • Hydrochloric Acid Transfer
  • Paper & Pulp Industries
  • Steel Pickling Lines
  • Caustic soda plants:
    Chlorinated Brine , Conc. HCL ,Dilute H SO etc. 2 4
  • PHOSPHORIC ACID PLANTS:
    H3PO4 , H2SO4 , HF and their mixtures with or without solid (gypsum) up to 40% conc.
  • Gas Washing Plants:
    Scrubbed Liquids containing Cl₂ , Br₂ , F₂ , I₂ , SO₂ , SO₃ , CO₂ , NH₃ , Gases etc. with solids replace Hast Alloy.
  • Rayon Plants :
    Spin bath solution (H₂SO₄ , ZNSO₄ , NaSo₄ , etc.)
  • Electro Plating

Temperature Resistance

• PP: 50–80°C
• PPH: 90–100°C
• PVDF: 100–115°C

Material Of Construction

• CASING:
Injection-moulded one-piece casing with top-centreline discharge and integrated flanges. Available in PP, PVDF, and UHMWPE materials.
• IMPELLER:
Hydraulically balanced semi-open impeller with precision-machined flow passages for high efficiency and improved NPSH performance. Available in PP, PVDF, and UHMWPE.
• SHAFT:
SS 304 shaft protected with Alloy-20, Alumina, PTFE, or Ceramic shaft sleeves.
• BEARING HOUSING:
Heavy-duty graded cast iron construction.
• BEARING:
SKF Ball Bearings.
• MECHANICAL SEAL:
Rotary seal faces are manufactured from PTFE, with stationary faces in high-purity Alumina Ceramic.
• DISTANCE PIECE:
Heavy-duty one-piece injection-moulded polypropylene construction.

Rating Chart
