IMPMD Series Seal-less Magnetic Drive Pump
IMPMD Series Seal-less Magnetic Drive Pump 02
IMPMD Series Seal-less Magnetic Drive Pump 03

IMPMD Series Seal-less Magnetic Drive Pump

₹100.00

Buy now
The magnetic drive design eliminates the conventional method of shaft coupling. This makes the pump casing fully sealed from the drive end, eliminating the need for conventional sealing systems. There is no seal used, so there are no troublesome seal repairs, replacements, leakage, or production loss. The impeller and drive magnets are permanent rare earth magnets, which prevent slippage and ensure that full motor horsepower is converted into pumping power. All pumps are rated for continuous duty with class “E” insulation. These pumps are centrifugal semi-open impeller type pumps and require priming before startup. SS-316 magnetic pumps are available up to 5 HP.
Add to wishlist
ENQUIRY!
Categories: , Brand:

Additional information

brand

Impala

Applications

The IMPMD Series magnetic drive pumps are ideal for transferring corrosive chemicals, plating chemicals, acids, dyes, solvents, toxic and fuming liquids, petrol, kerosene, etc. They are widely used in the following industries:

  • Chemical industries
  • Pharmaceuticals
  • Food processing industries
  • Electroplating, galvanizing, and anodizing plants
  • Laboratory equipment and PCB plants
  • Medical equipment and X-ray film plants
  • Textile dyeing houses
  • Liquid dispensing machines and chemical filtration equipment
  • Hazardous duty conditions with flame-proof motors

High efficiency is achieved due to the permanent magnet power coupling.

Advantageous Features

  • 100% leak-proof pumps due to magnetic drive arrangement
  • No shaft seal used, solving the problem of seal leakage, wear & tear
  • Friction-free operation for reduced power consumption
  • High power permanent magnets ensure full power transfer and eliminate slippage
  • All pumping parts are non-metallic, offering superior corrosion resistance
  • Simple and easy to operate
  • Long life, reliable, and trouble-free operation

Range

  • Capacity: From 10 LPM up to 750 LPM
  • Head: Up to 40 m
  • Material of Construction: Glass-filled polypropylene (PP), PVDF: Up to 110°C
  • Operating Temperature:
    • PP: up to 80°C
    • PVDF: up to 110°C
    • Special models: Up to 150°C
    • SS 316 models: Up to 250°C

Specification
