Additional information
| brand | Impala |
|---|
- Additional information
- Application
- Features
- SHP-RE Specification
- SHP-OF Specification
- CMS Specification
Application
- Irrigation – Sprinkler installations, water works, fire fighting, mining
- Fuel pumping, handling volatile liquids, wash-down applications
- Hydraulic press / circuits, transfer & circulation of hot & cold water
- Boiler feed pumps, condensate pumps
Features
- Vertically split suction, intermediate, and discharge casings clamped together by external tie bolts and sealed with gaskets.
- Grease-lubricated antifriction bearings designed to meet the requirements, mounted on one or both sides.
- Pump uses soft graphite-lubricated asbestos. Special design of stuffing boxes with mechanical seals are available.
- The suction and discharge nozzles are top vertical.
- The flanges are oval flange around the flange as required by the design.
- The round flanges, when provided, correspond to international standards.
- The direction of rotation is clockwise as viewed from the driving end.
- For suction more than 4 MLC, the capacity reduces, and the pump must be filled with liquid before it is started for the first time.
SHP-RE Specification
- Sizes: 1″ to 2.1/2″
- Capacity: 550 LPM
- Head: 280 MLC Max
- Temperature: 100°C Max, more available on request
- Suction Lift: 8 MLC Max
SHP-OF Specification
- Sizes: 1″ to 2.1/2″
- Capacity: 550 LPM
- Head: 280 MLC Max
- Temperature: 100°C Max, more available on request
- Shaft Sleeve: SS – 410
- Suction Lift: 8 MLC Max
CMS Specification
- Sizes: 1″ to 2.1/2″ and 3″ to 5″
- Capacity: 2500 LPM
- Head: 80 MLC Max
- Suction Lift: 8 MLC Max
