Additional information
| brand | Impala |
|---|
Features
- Built-in or external relief valve options
- Various sealing options with internal/outside mounted seals
- Pumps offered in Cast Iron, Cast Steel, and Stainless Steel
- Replacing the vane is simple and easy
- Vanes are self-adjusting for wear, ensuring long-lasting performance
- Vanes made of stainless steel, bronze, carbon, PTFE
- Virtually pumps any liquid and handles any viscosity
- Higher pump capacities compared to gear pumps and lobe pumps
- Requires low NPSH, making it ideal for handling liquid gas like LPG, Butane
- Wide range of capacities from 10 LPM to 5000 LPM
Technical Specifications
| MODEL | INLET/OUTLET SIZE | DISPLACEMENT FOR 100 REV IN LITERS | CAPACITY 100 REV LITERS | CAPACITY AT MAX SPEED LITERS/HR |
|---|---|---|---|---|
| LV-15 | ½” X ½” | 1440 | 1.75 | 1500 |
| LV-25 | 1” X 1” | 1440 | 3.4 | 3200 |
| LV-40 | 1 ½” X 1 ½” | 1440 | 10.3 | 9000 |
| LV-2 | 2” X 2” | 960 | 38 | 18000 |
| LV-3 | 3” X 3” | 960 | 50 | 28000 |
| LV-4 | 4” X 4” | 600 | 150 | 80000 |
| LV-5 | 5” X 5” | 500 | 240 | 90000 |
| LV-6 | 6” X 6” | 500 | 350 | 125000 |
