The SDG-180 is a compact and efficient single-phase synchronous alternator powered by a reliable F-210 diesel engine. Designed for industrial and domestic use, it delivers consistent power output while ensuring durability and easy operation.
| brand | Impala |
|---|
| Parameter | SDG-180 Generator | Engine (F-210 Diesel) |
|---|---|---|
| Type | Single Phase Synchronous Alternator | Single Cylinder, Vertical, 4 Stroke, Air Cooled, D.I. Diesel Engine |
| Frequency (Hz) | 50 | – |
| Max. Output (kW) | 1.8 | – |
| Rated Output (kW) | 1.6 | – |
| Voltage (V) | 220 | – |
| DC Output | 12V x 8.3A (Optional) | – |
| Power Factor | 1 | – |
| Excitation System | Self-Excitation | – |
| Displacement | – | 219 cc |
| Bore x Stroke (mm) | – | 70 x 57 |
| Max. Output RPM/HP | – | 3000 / 3 HP |
| Starting System | – | Recoil Starter |
| Ignition System | – | TCI (Transistorized Pointless) |
| Lube Oil Capacity | – | 0.75 L |
| Oil Alert | – | / |
| Dimensions LxWxH (mm) | 700 x 450 x 550 | – |
| Weight | – | 42 kg |
